The Draper Access V [NTSC 4:3] Tab-Tensioned ceiling-recessed Electric Screen 10' (72" x 96") 140104U is a high-quality projection screen designed to deliver exceptional visual performance for professional presentations, home theaters, or any other application that requires a large, clear viewing surface.

With its tab-tensioned design, the screen surface is kept taut and flat, ensuring a smooth and uniform projection surface. This eliminates any wrinkles or waves that may distort the image, resulting in a crisp and vibrant display. The tab-tensioning system also enhances the screen's durability and longevity, as it prevents sagging or stretching over time.

The screen is designed for ceiling-recessed installation, allowing it to seamlessly blend into the surrounding architecture when not in use. The electric motorized mechanism enables effortless operation, allowing you to raise or lower the screen with a simple touch of a button. This makes it convenient and easy to set up the screen according to your specific needs.

Featuring an NTSC 4:3 aspect ratio, the screen is suitable for displaying traditional television and computer content. The dimensions of 72" x 96" provide a generous viewing area, making it ideal for medium-sized venues or rooms. The screen's 10-foot diagonal measurement ensures a large and immersive viewing experience, capturing the attention of your audience and enhancing the impact of your presentations or movies.

The Draper Access V [NTSC 4:3] Tab-Tensioned ceiling-recessed Electric Screen 10' (72" x 96") 140104U is crafted with high-quality materials to ensure excellent image reproduction and long-lasting performance. It combines functionality, versatility, and aesthetics to deliver a top-notch projection solution that meets the needs of professionals and home theater enthusiasts alike.

Product Specs

•  Case dimensions are 7-3/8" high x 8-1/16" deep (19 cm x 20 cm), includes trim flange. Built-in controls may increase case length. Mounting brackets may add to case dimensions, see Submittal in the Technical Documents tab for details.

•  Maximum image width up to 16' (488 cm) wide, depending on surface selection.

•  The standard Access is a good alternative whenever the above-ceiling space permits. Access Fit is recommended when space is at a premium.

•  Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.

•  Adjustable or removable hoisting brackets included for easy lifting during installation.

•  Sliding brackets on top of the case allow for adjustments for mounting.

•  Sliding brackets inside case accommodate different size screens.

•  Bottom closure panel detachable or hangs in place with “T” bracket to provide accessibility for service or maintenance.

•  Quick-connect wiring allows for early installation of the case with the addition of the screen later.

•  Low voltage, video interface or other controls can be built into housing for below ceiling access.

•  Includes a 110V, 3-position switch (standard). Quiet, low voltage motors and 220V options are available.

•  White case standard, black available upon request.

•  Custom sizes available.

•  UL Listed.
